Cable AAAC Cairo 465.4
What is AAAC Cairo cable 465.4?
Cable AAAC Cairo 465.4 It is an option commonly used in electrical systems for distribution and aerial transmission., at both primary and secondary levels. Besides, Can be used for grounding purposes in electrical projects.
This driver offers a remarkable strength-to-weight ratio thanks to its durable aluminum alloy. Its design includes a 6201-T81 aluminum alloy conductor, concentrically braided, known for its corrosion resistance.
AAAC conductors are specifically designed to optimize strength-to-weight ratio, providing excellent electrical performance, Sinking stress characteristics and high corrosion resistance.
AAAC Cairo Cable Standard 465.4
B398 6201-T81 Aluminum Alloy Cable for Electrical Purposes.
B399 Concentric Stranded 6201-T81 Aluminum Alloy Conductors.
AAAC Cairo Cable technical data 465.4
| Code | Driver size | Stranding | Section area | Driver diameter | linear mass | Rated force | DC resistance to 20 ℃ |
| Kcmil | Number/mm | mm2 | mm | Kg/km | kgf | Oh/km | |
| Cairo | 465.4 | 19/3.98 | 235.80 | 19.89 | 645.70 | 7097 | 0.14310 |
Cairo Apps 465.4
Cairo 465.4 It is designed with a high-strength aluminum alloy, which provides a good relationship between strength and weight.
Primary and Secondary Distribution: This cable is widely used in electrical distribution networks for power transmission at primary and secondary levels., in both urban and rural areas.
Overhead Transmission Lines: Due to its ability to withstand heavy loads and adverse weather conditions, It is used in medium and high voltage overhead power transmission lines..
Electrical substations: In connection applications between electrical substations, This cable can be used to connect transformers and other electrical equipment.
Cairo 465.4 It is versatile and used in a variety of applications in electrical distribution systems, thanks to its high resistance, lightness and corrosion resistance.
Cairo 465.4 It is a reliable and adaptable conductor used in various applications in electrical distribution systems, thanks to its resistance qualities, lightness and corrosion resistance.
