Cable AAAC Elgin 652.4
What is AAAC Elgin cable 652.4?
Cable AAAC Elgin 652.4 It is widely used in distribution and air transmission services, at both primary and secondary levels. Besides, Can be used for grounding purposes in electrical projects.
Thanks to its durable aluminum alloy, This driver achieves an excellent weight-to-strength ratio. Its design includes a concentric stranded conductor made of 6201-T81 aluminum alloy, Recognized for its corrosion resistance.
AAAC conductors are meticulously designed to optimize strength-to-weight ratio, offering optimal electrical performance, ideal tensile characteristics and remarkable corrosion resistance.
AAAC Elgin Cable Standard 652.4
B398 6201-T81 Aluminum Alloy Cable for Electrical Purposes.
B399 Concentric Stranded 6201-T81 Aluminum Alloy Conductors.
AAAC Elgin Cable technical data 652.4
| Code | Driver size | Stranding | Section area | Driver diameter | linear mass | Rated force | DC resistance to 20 ℃ |
| Kcmil | Number/mm | mm2 | mm | Kg/km | kgf | Oh/km | |
| Elgin | 652.4 | 19/4.71 | 330.60 | 23.55 | 970.60 | 9942 | 0.10120 |
Elgin Applications 652.4
Elgin 652.4, thanks to its robust design with a high-strength aluminum alloy, finds multiple applications in electrical distribution systems.
Deployed in Urban and Rural Networks: This cable is widely used for power transmission at primary and secondary levels in urban and rural electrical networks..
Facing High Tension Challenges: Its ability to withstand heavy loads and adverse weather conditions makes it the preferred choice for medium and high voltage overhead power transmission lines..
Vital Connections in Substations: In the heart of electrical substations, elgin 652.4 plays a crucial role when connecting transformers and other electrical equipment.
Its versatility and reliability are highlighted thanks to its exceptional resistance, light weight and durability against corrosion. In summary, elgin 652.4 It is an essential conductor in electrical distribution systems, offering robust solutions for various applications.
